CuAl8Ni2 Thermal Spray Wire Good Resistance To Corrosion Metal Wire Alloy Wire Aluminium Bronze Alloy
| Place of Origin | China |
|---|---|
| Brand Name | WL-ALLOTECH |
| Model Number | CuAl8Ni2 wire |
| Minimum Order Quantity | 5kg |
| Price | Negotiable |
| Packaging Details | 15kg/spool |
| Delivery Time | within 10 days |
| Payment Terms | L/C, T/T |
| Supply Ability | 300 tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | CuAl8Ni2 Thermal Spray Wire | Raw Material | Cu Al Fe Mn Ni Other |
|---|---|---|---|
| Density | 7.5kg/dm³ | Elongation | 30% |
| Hardness | 130HB | Standard | BS EN14640 |
| Spool Type | No Recycled Material | Dimensions | 1.6 Mm, 2.0 Mm, 3.17 Mm |
| Solids Temperature | 1030°C | Liquids Temperature | 1050°C |
| Spray Wire State | Semi-hard State | Tensile Strength | 430N/mm² |
| Certificate | ISO 9001 | Test Report | Mill-certificate |
| High Light | CuAl8Ni2 Thermal Spray Wire,Thermal Spray Wire 3.17mm,130HB metal wire |
||
Product Description
CuAl8Ni2 Thermal Spray Wire Good Resistance To Corrosion Metal Wire Alloy Wire Aluminium Bronze Alloy
Product Description
CuAl8Ni2 is recommended for the overlying of copper-aluminium alloys, Aluminium coated steel in machinery and chemical industry as well as for iron welding in shipbuilding. Also excellent for the welding of brass tube and copper-aluminium that requires resistance to erosion.
Surface Preparation
Surface should be clean, white metal, with no oxides (rust), dirt, grease, or oil on the surface to be coated. Note: It is best not to handle surfaces after cleaning.
Recommended method of preparation is, to grit blast with 24 mesh aluminum oxide, rough grind, or rough machine in a lathe.
Chemical Composition(%)
| Standard | Cu | Al | Fe | Mn | Ni | other |
| BS EN14640 | Rest | 8 | 2 | 1.5 | 2 | <0.5 |
Typical Physical Properties
|
Solids Temperature |
Density | Elongation |
Liquids Temperature |
Tensile Strength |
Brinell Hardness |
| 1030°C | 7.5kg/dm³ | 30% | 1050°C | 430N/mm² | 130HB |
Packing Details
|
Diameter |
DimensionTolerance |
Packing |
Wire Weight |
|
1/16"(1.6mm) |
+0/-0.05 |
D 300 Spool |
15kgs(33 lbs)/spool |
|
2.0mm |
+0/-0.05 |
D 300 Spool |
15kgs(33 lbs)/spool |
|
1/8"(3.17mm) |
+0/-0.05 |
Coil Form |
20-400kgs/coil |
Other sizes can be produced by customers’ requirement.
Applications
· Electronic industry
· Good resistance to corrosion
Type We Could Offer
Thermal spray wire-Nickel based
|
WL TYPE |
Tafa |
PMET |
Metco |
Size |
|
WL-NiAl95/5 |
75B |
885 |
8400 |
1.6/2.0/3.17mm |
|
WL-NiAl80/20 |
79B |
884 |
405 |
2.0/3.17mm |
|
WL-NiCr80/20 |
06C |
821 |
8450 |
1.6/2.0/3.17mm |
|
WL-Monel400 |
70T |
877 |
Monel |
1.6/2.0/3.17mm |
|
WL-NiCrTi |
45CT |
889 |
8500 |
1.6/2.0/3.17mm |
|
WL-Inconel718 |
78T |
818 |
8718 |
1.6/2.0/3.17mm |
|
WL-Inconel625 |
71T |
860 |
8625 |
1.6/2.0/3.17mm |
|
WL-Alloy-C276 |
77T |
876 |
8276 |
1.6/2.0/3.17mm |
|
WL-NiCrAl(P) |
73MXC |
886 |
8443 |
1.6/2.0mm |
|
WL-NiCrAlY(P) |
76MXC |
887 |
884 |
1.6/2.0mm |
|
WL-NiMoAl(P) |
74MXC |
888 |
8447 |
1.6/2.0mm |
Thermal spray wire-Iron based
|
WL TYPE |
Tafa |
PMET |
Metco |
Size |
|
WL-SS420 |
60T |
720 |
Metcoloy 2 |
1.6/2.0/3.17mm |
|
WL-SS304/304L |
80T |
710 |
Metcoloy 1 |
1.6/2.0/3.17mm |
|
WL-SS316/316L |
85T |
730 |
Metcoloy 4 |
1.6/2.0/3.17mm |
|
WL-FeCrAl |
Alcro |
731 |
|
1.6/2.0mm |
|
WL-FeCrBSi(P) |
95MXC |
273 |
|
1.6/2.0mm |
|
WL-FeCrNiB(P) |
96MXC |
|
|
1.6/2.0mm |
|
WL-Tungsten Carbide(P) |
97MXC |
297 |
Duocor |
1.6/2.0mm |
|
WL-LCr Carbide(P) |
98MXC |
223 |
|
1.6/2.0mm |
|
WL-FeAl(P) |
35MXC |
50 |
|
1.6/2.0mm |
|
WL-HCr Carbide(P) |
|
226 |
Sm8222 |
1.6/2.0mm |
Thermal spray wire-Copper based
|
WL TYPE |
Tafa |
PMET |
Metco |
Size |
|
WL-Pure Copper |
|
|
|
1.6/2.0/3.17mm |
|
WL-CuSn1 |
05T |
|
|
1.6/2.0/3.17mm |
|
WL-CuAl8 |
|
|
Sprabronze AB |
1.6/2.0/3.17mm |
|
WL-CuAl10 |
10T |
590 |
Sprabronze AA |
1.6/2.0/3.17mm |
Thermal spray wire-Zinc & Aluminium based
|
WL TYPE |
Tafa |
PMET |
Metco |
Size |
|
WL-Pure Al |
01T |
699 |
Aluminum |
1.6/2.0/3.17mm |
|
WL-Pure Al Grade 1100 |
|
|
|
1.6/2.0/3.17mm |
|
WL-Pure Zn |
02Z |
540 |
Zinc |
1.6/2.0/3.17mm |
|
WL-AlMg5 |
|
|
Metco AlMg |
1.6/2.0/3.17mm |
|
WL-ZnAl85/15 |
02A |
|
Zn/Al |
1.6/2.0/3.17mm |
Thermal spray wire-Other based alloy
|
WL TYPE |
Tafa |
PMET |
Metco |
Size |
|
WL-Molybdenum wire |
13T |
899 |
Sprabond |
1.6/2.0/3.17mm |
|
WL-Babbitt wire |
04T |
542 |
Sprababbitt |
1.6/2.0/3.17mm |
|
WL-Tin wire |
02W |
549 |
Metco Tin |
1.6/2.0mm |
|
WL-Ti wire |
14T |
|
|
1.6/2.0mm |
