CuAl9Ni5 Spray Wire Thermal Alloy Wire Metal Wire Propellers Bearing Weights Valves Pumps And Pipe System
| Place of Origin | China |
|---|---|
| Brand Name | WL-ALLOTECH |
| Model Number | CuAl9Ni5 |
| Minimum Order Quantity | 5kg |
| Price | Negotiable |
| Packaging Details | 15kg/spool |
| Delivery Time | within 10 days |
| Payment Terms | L/C, T/T |
| Supply Ability | 300 tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | CuAl9Ni5 Thermal Spray Wire | Elongation | 10% |
|---|---|---|---|
| Liquids Temperature | 1045°C | Solids Temperature | 1015°C |
| Density | 7.5kg/dm³ | Standard | BS EN14640 |
| Spool Type | No Recycled Material | Dimensions | 1.6 Mm, 2.0 Mm, 3.17 Mm |
| Raw Material | Cu Al Fe Mn Ni Other | Spray Wire State | Semi-hard State |
| Tensile Strength | 450N/mm² | Hardness | 150HB |
| Certificate | ISO 9001 | Test Report | Mill-certificate |
| High Light | CuAl9Ni5 Spray Wire,Spray Wire Thermal,1.6mm wire spray |
||
Product Description
CuAl9Ni5 Thermal Spray Wire Alloy Wire Metal Wire Spray Wire Propellers Bearing Weights Vlaves Pumps Pipe Systerm
Product Description
CuAl9Ni5 is used to join and repair wrought and cast nickel aluminium bronze materials. It is best for the fabrication or repair of ship fittings and propellers, and other components subject to salt and brackish water.
Surface Preparation
Surface should be clean, white metal, with no oxides (rust), dirt, grease, or oil on the
surface to be coated. Note: It is best not to handle surfaces after cleaning.
Recommended method of preparation is, to grit blast with 24 mesh aluminum oxide,
rough grind, or rough machine in a lathe.
Chemical Composition(%)
| Standard | Cu | Al | Fe | Mn | Ni | other |
|
BS EN14640 |
Rest | 9 | 3.8 | 1 | 4.5 | <0.5 |
Typical Physical Properties
|
Solids Temperature |
Density | Elongation |
Liquids Temperature |
Tensile Strength |
Brinell Hardness |
| 1015°C | 7.5kg/dm³ | 10% | 1045°C | 450N/mm² | 150HB |
Packing Details
|
Diameter |
DimensionTolerance |
Packing |
Wire Weight |
|
1/16"(1.6mm) |
+0/-0.05 |
D 300 Spool |
15kgs(33 lbs)/spool |
|
2.0mm |
+0/-0.05 |
D 300 Spool |
15kgs(33 lbs)/spool |
|
1/8"(3.17mm) |
+0/-0.05 |
Coil Form |
20-400kgs/coil |
Other sizes can be produced by customers’ requirement.
Applications
· Welding casting
· Propellers, bearing weights, vlaves, pumps and pipe systerms
· Very good corrosion resistance to seawater.
Type We Could Offer
Thermal spray wire-Nickel based
|
WL TYPE |
Tafa |
PMET |
Metco |
Size |
|
WL-NiAl95/5 |
75B |
885 |
8400 |
1.6/2.0/3.17mm |
|
WL-NiAl80/20 |
79B |
884 |
405 |
2.0/3.17mm |
|
WL-NiCr80/20 |
06C |
821 |
8450 |
1.6/2.0/3.17mm |
|
WL-Monel400 |
70T |
877 |
Monel |
1.6/2.0/3.17mm |
|
WL-NiCrTi |
45CT |
889 |
8500 |
1.6/2.0/3.17mm |
|
WL-Inconel718 |
78T |
818 |
8718 |
1.6/2.0/3.17mm |
|
WL-Inconel625 |
71T |
860 |
8625 |
1.6/2.0/3.17mm |
|
WL-Alloy-C276 |
77T |
876 |
8276 |
1.6/2.0/3.17mm |
|
WL-NiCrAl(P) |
73MXC |
886 |
8443 |
1.6/2.0mm |
|
WL-NiCrAlY(P) |
76MXC |
887 |
884 |
1.6/2.0mm |
|
WL-NiMoAl(P) |
74MXC |
888 |
8447 |
1.6/2.0mm |
Thermal spray wire-Iron based
|
WL TYPE |
Tafa |
PMET |
Metco |
Size |
|
WL-SS420 |
60T |
720 |
Metcoloy 2 |
1.6/2.0/3.17mm |
|
WL-SS304/304L |
80T |
710 |
Metcoloy 1 |
1.6/2.0/3.17mm |
|
WL-SS316/316L |
85T |
730 |
Metcoloy 4 |
1.6/2.0/3.17mm |
|
WL-FeCrAl |
Alcro |
731 |
|
1.6/2.0mm |
|
WL-FeCrBSi(P) |
95MXC |
273 |
|
1.6/2.0mm |
|
WL-FeCrNiB(P) |
96MXC |
|
|
1.6/2.0mm |
|
WL-Tungsten Carbide(P) |
97MXC |
297 |
Duocor |
1.6/2.0mm |
|
WL-LCr Carbide(P) |
98MXC |
223 |
|
1.6/2.0mm |
|
WL-FeAl(P) |
35MXC |
50 |
|
1.6/2.0mm |
|
WL-HCr Carbide(P) |
|
226 |
Sm8222 |
1.6/2.0mm |
Thermal spray wire-Copper based
|
WL TYPE |
Tafa |
PMET |
Metco |
Size |
|
WL-Pure Copper |
|
|
|
1.6/2.0/3.17mm |
|
WL-CuSn1 |
05T |
|
|
1.6/2.0/3.17mm |
|
WL-CuAl8 |
|
|
Sprabronze AB |
1.6/2.0/3.17mm |
|
WL-CuAl10 |
10T |
590 |
Sprabronze AA |
1.6/2.0/3.17mm |
Thermal spray wire-Zinc & Aluminium based
|
WL TYPE |
Tafa |
PMET |
Metco |
Size |
|
WL-Pure Al |
01T |
699 |
Aluminum |
1.6/2.0/3.17mm |
|
WL-Pure Al Grade 1100 |
|
|
|
1.6/2.0/3.17mm |
|
WL-Pure Zn |
02Z |
540 |
Zinc |
1.6/2.0/3.17mm |
|
WL-AlMg5 |
|
|
Metco AlMg |
1.6/2.0/3.17mm |
|
WL-ZnAl85/15 |
02A |
|
Zn/Al |
1.6/2.0/3.17mm |
Thermal spray wire-Other based alloy
|
WL TYPE |
Tafa |
PMET |
Metco |
Size |
|
WL-Molybdenum wire |
13T |
899 |
Sprabond |
1.6/2.0/3.17mm |
|
WL-Babbitt wire |
04T |
542 |
Sprababbitt |
1.6/2.0/3.17mm |
|
WL-Tin wire |
02W |
549 |
Metco Tin |
1.6/2.0mm |
|
WL-Ti wire |
14T |
|
|
1.6/2.0mm |
