Al2O3-40TiO2 Metco 131 Thermal Spray Powder Pump Components Shaft Sleeves Mechanical Seals
| Place of Origin | China |
|---|---|
| Brand Name | WL-ALLOTECH |
| Model Number | Al2O3-40TiO2 Powder |
| Minimum Order Quantity | 5kg |
| Price | Negotiable |
| Packaging Details | 5kg/bottles, 4 bottles pack in one carton |
| Delivery Time | within 10 days |
| Payment Terms | L/C, T/T |
| Supply Ability | 300 tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Chemistry | Al2O3 40TiO2 | Morphology | Angular And Blocky Or Spheroidal |
|---|---|---|---|
| Shape | Powder | Color | Gray |
| Melting Point | Approx. 1840 °C (3340 °F) | Service Temperature | ≤ 540 °C (1000°F) |
| Manufacture | Fused And Crushed | Type | Wear Resistant Material |
| Raw Material | Aluminum Oxide Powder | Classification | Classification Oxide ceramic |
| Certificate | ISO 9001 | Test Report | Mill-certificate |
| High Light | Metco 131 Thermal Spray Powder,Al2O3-40TiO2 Thermal Spray Powder,metco powder |
||
Product Description
Al2O3-40TiO2 Metco 131 Powder Thermal Spray Powder Pump Components Shaft Sleeves Mechanical Seals
Product Description
Different with other basic Al2O3-40TiO2 powder, size -45/+5µm its color in white and spheroidal morphology by agglomerated production process. Although chemical composition very similar with regular type, performance is better. Due to its special size particle, they mostly used for better flow-ability performance and produce wear resistance coatings, also easily finishing for types of surface texture. Its developed for combustion powder spray process
Equivalent to: Metco 131, FST C-341/342/343, Praxair ALO-121, Amperit 745
Chemical Composition
| Al2O3 | TiO2 | SiO2(max) | Fe2O3(max) | MgO(max) | CaO(max) |
| balance | 38.5%-41.5% | 0.5% | 0.3% | 0.2% | 0.1% |
Physical Properties
| Classification | Oxide ceramic, alumina based |
| Chemistry | Al2O3 40TiO2 |
| Manufacture | Various (see Section 2.2) |
| Morphology | Angular and blocky or spheroidal |
| Purpose | Wear and chemical resistance |
| Service Temperature | ≤ 540 °C (1000°F) |
| Melting Point | approx. 1840 °C (3340 °F) |
| Process | Atmospheric plasma spray orcombustion powder Thermospray™ |
Packing Details
| Granularity |
-15 +45μm other size can be customized |
| Packing | 5 kg/bottle 4 bottles/box |
Typical uses and Applications
■ Chemical processing industry to resist weak acidic environments
■ Textile manufacturing equipment and tooling
■ Pump components, shaft sleeves and mechanical seals used in a variety of industries
Type We Could Offer
Thermal spray powder-Oxide ceramic
| WL TYPE | Metco | Size |
| WL-Al2O3 | Metco 105SFP | Customized |
| WL-Al2O3 13TiO2 | Metco 6221 | Customized |
| WL-Al2O3 40TiO2 | Metco 131VF | Customized |
| WL-Cr2O3 | Metco 106NS | Customized |
| WL-Cr2O3 5SiO2 3TiO2 | Metco 136F | Customized |
| WL-TiO2 | Metco 6231A, 6232B, 6233C | Customized |
| WL-TiO2 45CrO3 | Metco 111 | Customized |
| WL-ZrO2 8Y2O3 | Metco 6608 |
Customized |
| WL-ZrO2 24MgO | Metco 210 | Customized |
